Ball Lock PVC Coated Stainless Steel Cable Ties
Category：
Detailed
Ball Lock PVC Coated Stainless Steel Cable Ties | Heavy-Duty Metal Zip Ties
(Self-Locking, Corrosion-Resistant, Industrial-Grade Security)
Product Highlights
✅ Roller Ball Locking Mechanism – Secure, vibration-proof grip for critical applications.
✅ PVC-Coated Stainless Steel – Extra edge protection against corrosion (ideal for dissimilar metals).
✅ Fully Enclosed Head – Prevents dirt/grit interference, ensuring long-term reliability.
✅ Wide Temperature Range – Stable performance from -40°C to +85°C (harsh environment ready).
✅ Fireproof & Chemical-Resistant – Meets CE, ROHS, REACH, TSCA, and Halogen-Free standards.
Technical Specifications
| Feature | Details |
|---|---|
| Material | Stainless Steel 201/304/316 with soft PVC coating |
| Lock Type | Self-locking roller ball mechanism (metallic buckle for easy ID) |
| Flammability | Fireproof (no melting/dripping) |
| Surface Finish | PVC coated – smoother edges vs. polyester-coated alternatives |
| Packaging | 50pcs/bag or 100pcs/bag – bulk discounts available. |
| ITEM NO. | LENGTH | WIDTH | THICKNESS | BUNDLE DIAMETER | TENSILE STRENGTH | ||
| INCH | MM | MM | MM | MM (MAX) | LBS | KGS | |
| MZS1-4.6x100 | 3.9" | 100 | 4.6 | 0.35 | 25 | 130 | 60 |
| MZS1-4.6x150 | 5.9" | 150 | 4.6 | 0.35 | 35 | 130 | 60 |
| MZS1-4.6x200 | 7.9" | 200 | 4.6 | 0.35 | 50 | 130 | 60 |
| MZS1-4.6x250 | 9.8" | 250 | 4.6 | 0.35 | 63 | 130 | 60 |
| MZS1-4.6x300 | 11.8" | 300 | 4.6 | 0.35 | 76 | 130 | 60 |
| MZS1-4.6x350 | 13.8" | 350 | 4.6 | 0.35 | 95 | 130 | 60 |
| MZS1-4.6x400 | 15.7" | 400 | 4.6 | 0.35 | 102 | 130 | 60 |
| MZS1-4.6x500 | 19.7" | 500 | 4.6 | 0.35 | 145 | 130 | 60 |
| MZS1-4.6x600 | 23.6" | 600 | 4.6 | 0.35 | 175 | 130 | 60 |
| MZS1-4.6x680 | 26.7" | 680 | 4.6 | 0.35 | 195 | 130 | 60 |
| MZS1-4.6x750 | 29.5" | 750 | 4.6 | 0.35 | 220 | 130 | 60 |
| MZS1-4.6x840 | 33" | 840 | 4.6 | 0.35 | 250 | 130 | 60 |
| MZS1-4.6x900 | 35.4" | 900 | 4.6 | 0.35 | 270 | 130 | 60 |
| MZS1-4.6x1050 | 41.33" | 1050 | 4.6 | 0.35 | 285 | 130 | 60 |
| MZS1-7.9x200 | 7.9" | 200 | 7.9 | 0.35 | 50 | 220 | 100 |
| MZS1-7.9x250 | 9.8" | 250 | 7.9 | 0.35 | 63 | 220 | 100 |
| MZS1-7.9x300 | 11.8" | 300 | 7.9 | 0.35 | 76 | 220 | 100 |
| MZS1-7.9x350 | 13.8" | 350 | 7.9 | 0.35 | 89 | 220 | 100 |
| MZS1-7.9x400 | 15.7" | 400 | 7.9 | 0.35 | 102 | 220 | 100 |
| MZS1-7.9x450 | 17.7" | 450 | 7.9 | 0.35 | 115 | 220 | 100 |
| MZS1-7.9x500 | 19.7" | 500 | 7.9 | 0.35 | 128 | 220 | 100 |
| MZS1-7.9x550 | 21.7" | 550 | 7.9 | 0.35 | 141 | 220 | 100 |
| MZS1-7.9x600 | 23.6" | 600 | 7.9 | 0.35 | 154 | 220 | 100 |
| MZS1-7.9x650 | 25.6" | 650 | 7.9 | 0.35 | 167 | 220 | 100 |
| MZS1-7.9x800 | 31.5" | 800 | 7.9 | 0.35 | 193 | 220 | 100 |
| MZS1-7.9x1050 | 41.33" | 1050 | 7.9 | 0.35 | 206 | 220 | 100 |
| MZS1-7.9x1200 | 48" | 1200 | 7.9 | 0.35 | 206 | 220 | 100 |
| MZS1-12x300 | 11.8" | 300 | 12.0 | 0.45 | 78 | 330 | 150 |
| MZS1-12x360 | 14.1" | 360 | 12.0 | 0.45 | 78 | 330 | 150 |
| MZS1-12x400 | 15.7" | 400 | 12.0 | 0.45 | 102 | 330 | 150 |
| MZS1-12x500 | 19.7" | 500 | 12.0 | 0.45 | 128 | 330 | 150 |
| MZS1-12x600 | 23.6" | 600 | 12.0 | 0.45 | 154 | 330 | 150 |
| MZS1-12x750 | 29.5" | 750 | 12.0 | 0.45 | 188 | 330 | 150 |
| MZS1-12x900 | 35.4" | 900 | 12.0 | 0.45 | 228 | 330 | 150 |
| MZS1-12x1100 | 43.6" | 1100 | 12.0 | 0.45 | 278 | 330 | 150 |
| MZS1-15x350 | 13.8" | 350 | 15.0 | 0.45 | 78 | 440 | 200 |
| MZS1-15x450 | 17.7" | 450 | 15.0 | 0.45 | 108 | 440 | 200 |
| MZS1-15x600 | 23.6" | 600 | 15.0 | 0.45 | 148 | 440 | 200 |
| MZS1-15x750 | 29.5" | 750 | 15.0 | 0.45 | 184 | 440 | 200 |
| MZS1-15x900 | 35.4" | 900 | 15.0 | 0.45 | 220 | 440 | 200 |
| MZS1-15x1100 | 43.3" | 1100 | 15.0 | 0.45 | 272 | 440 | 200 |
Key Advantages Over Nylon Cable Ties
🔹 Metal Core Strength – Higher tensile strength, resistant to cutting/chewing.
🔹 Corrosion Protection – PVC layer prevents galvanic corrosion between metals.
🔹 Visible Security – Metallic buckle distinguishes from standard black nylon ties.
Common Applications
🏭 Industrial – Securing high-voltage cables, marine equipment, and oil/gas pipelines.
⚡ Electrical – Bundling wires in substations or outdoor control panels.
🚢 Marine & Offshore – Saltwater-resistant for ship rigging and dock installations.
🔧 HVAC & Automotive – Heat-resistant hose/clamp retention in engines.
FAQ
❓ Can these be reused?
→ No, single-use design for permanent, tamper-proof security.
❓ Why choose PVC over polyester coating?
→ PVC is softer and thicker, offering better edge protection and corrosion resistance.
❓ How do I cut these ties?
→ Use heavy-duty cable tie cutters or diagonal pliers for clean removal.
